Apollo 3kVA Online UPS

Apollo 3kVA Online UPS comes with Single Phase input power: from 110Vac ~ 290Vac, DSP control technology with input power factor of >0.98% (Full Load). The Apollo series UPS are providing high performance power supply systems with Single Phase input and Single Phase output and galvanic isolation by high performance inverter output transformer designed to supply high-quality power on a permanent basis. In this Online UPS advanced diagnostics and unit information allow users to monitor system parameters and alarms, check the status of the battery and provide access to the history of events through the system software or multi-language screen. This new Apollo series Online UPS features with On-line UPS double conversion, Single Phase, input/ Single Phase output, DSP control technology, Galvanic insulation by output transformer, Reduced harmonic distortion, RFI filter, Acoustic and luminous signalling. This UPS Reduced harmonic distortion of output signal. This Online UPS also comes with High efficiency, Output power factor 0.8 ~1 (lagging), Software included for System Monitoring. In this online UPS, the Extended battery options available.

Main Features
Main Features	Capacity 3.0 KVA Load Capacity <110% load Continuous 110-125% load 12 minutes 125-150% load 10 minutes >150% load: by pass Input Voltage Single Phase, 110Vac ~ 290Vac Output Voltage 220Vac Frequency (Battery Mode) 50/ 60Hz Noise Level <53dB - 65dB at 1 meter distance Battery DC Voltage: 96VDC Backup time: 15 - 30 Minutes depending on Load Recharge time: 5 ~ 8 Hours Alarm Audio Alarm: Keep 90 Seconds at a time interval of 4 Seconds Battery Low: Auto Shutdown upon complete discharge of battery and auto turn-on upon recovery of utility power Fault: Continuous Alarming
Input Devices
Input Features	Frequency 50Hz (60Hz on Request) +/- 5% Power Factor >0.98% (Full Load)
Output Features
Output Features	Backup Time 15 - 30 Minutes depending on Load Voltage Range 220Vac +/- 5% Power Factor 0.8 ~ 1 (lagging) Type of Wave Pure Sinewave THD < 3%
Warranty
Warranty	Backup Time 15 - 30 Minutes depending on Load Voltage Range 220Vac +/- 5% Power Factor 0.8 ~ 1 (lagging) Type of Wave Pure Sinewave THD < 3%
